What is fatigue life with S-N curves and Miner's rule

TL;DR

S-N curves estimate how long a component lasts under cyclic loading by relating stress range to cycles to failure. The curves vary due to data scatter, so codes shift them downward to reduce failure probability. Techniques like Rainflow counting and Miner's rule help handle complex stress histories and accumulate fatigue damage.

Transcript

Components which are subjected to loading which varies with time can fail at stresses well below the material's ultimate strength. This is known as fatigue failure and it accounts for the vast majority of mechanical engineering failures worldwide. The bolts in an office chair, the crank arm on your bicycle, and pressurized oil pipelines, are just a... Read More

Key Insights

• Fatigue failure happens due to crack formation, growth, and eventual fracture under time varying loads.
• S-N curves plot cycles to failure against stress range and are used to predict fatigue life for given loading conditions.
• Endurance limit in some materials implies infinite life below a certain stress range and is key for high cycle fatigue design.
• Mean stress affects fatigue life and can be addressed with mean-stress corrections or Goodman Diagrams.
• Rainflow counting reduces complex stress histories to simple cycles suitable for damage calculations.
• Miner's rule sums the damage fractions from each cycle to predict total fatigue damage.
• Variability in fatigue data means published curves are typically shifted downward to reduce failure probability.
• If cracks are existing, Linear Elastic Fracture Mechanics provides an alternative life prediction method.
• More videos from this channel:
  • What is the difference between true and engineering stress?
  • How to apply Bernoulli's equation in fluid flow?
  • How does heat treatment change steel properties
• More from this channel: The Efficient Engineer

Questions & Answers

Q: How to estimate fatigue life using S-N curves?

To estimate fatigue life with S-N curves you perform fatigue tests on a test piece at different applied stress ranges and count the cycles to failure for each. Plot the results with the horizontal axis on a log scale representing cycles and the vertical axis as the stress range. Fit a curve through the data to obtain the S-N relationship for the material. Then use the curve to predict the number of cycles to failure for a given stress range in your component. If the design involves mean stresses or complex loading, apply mean-stress corrections or a Goodman diagram, or decompose the spectrum with Rainflow counting and use Miner’s rule to accumulate damage.

Q: What is the difference between high and low cycle fatigue?

High cycle fatigue involves low stress ranges and typically more than 10,000 cycles, with predominantly elastic deformation and life predicted by S-N curves. Low cycle fatigue involves higher stress ranges, fewer cycles, and both elastic and plastic deformation, often requiring a strain-based approach such as Coffin-Manson relations to predict fatigue life. Choosing the right regime affects the modeling approach and design safety margins.

Q: What does the endurance limit mean in fatigue analysis?

The endurance limit is the horizontal asymptote of the S-N curve at a very large number of cycles for some ferrous materials, suggesting the component could endure cyclic loading below this stress forever without fatigue failure. It serves as a design parameter indicating a safe stress range for infinite life, though not all materials exhibit a true endurance limit.

Q: How does Rainflow counting help with complex loading spectra?

Rainflow counting simplifies a complex, time-varying stress history into a finite set of simple, constant amplitude cycles. Each cycle is characterized by a stress range and mean stress, allowing the subsequent fatigue life analysis to apply standard S-N curves or other life prediction tools to these discrete cycles. This makes it possible to handle irregular loading conditions in a structured way.

Q: What is Miner's rule used for in fatigue analysis?

Miner's rule quantifies cumulative fatigue damage by summing the fractions of life used by each stress range cycle. For each cycle, you compute the number of cycles experienced divided by the number of cycles to failure at that stress range, then sum these fractions. If the total damage equals or exceeds one, fatigue failure is predicted, under the assumptions of constant amplitude sequences and independent cycles.

Q: How is mean stress accounted for in fatigue life predictions?

Mean stress can shorten fatigue life, so corrections are used when the mean stress is not zero. One approach uses S-N curves derived for specific mean stresses, but these curves are not always available or practical. Another common method is to apply a Goodman diagram to adjust the endurance limit based on the mean stress, ensuring designs remain safe under real loading.

Q: What should you do if there is an existing crack in the component?

If a crack is already present, S-N based life predictions are not suitable. Instead, use Linear Elastic Fracture Mechanics to determine a critical crack size that would cause fracture and apply a crack growth law to calculate the time required for the crack to reach that size. This approach directly accounts for crack size and growth rate.

Q: Why is there variability in fatigue test data, and how is it addressed?

Fatigue test data show substantial scatter due to material inconsistencies, surface finish, residual stresses, and testing conditions. To reduce the risk of unexpected failure, engineers fit a best-guess S-N curve and then shift it downward by a certain standard deviation to lower the predicted life, increasing design safety margins by accounting for statistical variability.

Summary & Key Takeaways

• Fatigue failure occurs when repeated loading forms and grows cracks until fracture happens, even below the material’s yield or ultimate strength. The S-N curve is built from fatigue tests that plot cycles to failure against stress range on a log scale to predict life.

• A practical design approach uses phase shifting of S-N curves to account for data variability and lower the probability of failure, moving the mean curve down by a standard deviation or more.

• For real loading, methods like Rainflow counting and Miner's rule decompose complex stress histories into simple cycles and sum damage to assess whether cumulative damage reaches a critical value of one, indicating failure.
