How to Analyze Android Supply Chain Images

TL;DR

Android system-image analysis must examine software from hardware suppliers, device manufacturers, and third parties, not merely standalone apps. Analysts need to reconstruct interactions across components because an apparently harmless preinstalled app may receive sensitive context from another source, store it, and transmit it remotely, while isolated code analysis reveals only part of that behavior.

Transcript

Okay, let's start. Welcome, everyone. Thank you for coming. Um, some years ago, I started working for a very small IT department, uh, in a, in a Polish company, and, um, this small IT department, uh, was, uh, doing everything. It was incident response, it was reverse engineering, malware analysis, even IT security projects. Um, and, uh, I highly re... Read More

Key Insights

• Android system images contain software from multiple sources, including code associated with hardware components, device assemblers, equipment manufacturers, and third-party feature providers. Reviewing only the operating system or visible applications can therefore leave relevant components outside the analysis.
• Hardware components require accompanying software that allows them to operate and become accessible to other parts of the device. From a reverse-engineering perspective, every hardware feature can add code to the system image and increase the amount of software requiring inspection.
• The Android supply chain separates responsibilities across organizations. An original device manufacturer combines hardware and supporting software, third parties may supply features such as software-based face unlock, and an original equipment manufacturer integrates and markets the finished phone.
• System-image testing covers several distinct dimensions. The described process includes Android compatibility testing, Google Mobile Services testing, hardware abstraction layer verification, checks that security patches were applied correctly, and a build test suite that reviews the image for malware or harmful behavior.
• The Android Compatibility Definition Document specifies requirements across many platform areas. Its security model coverage includes permissions, premium SMS warnings, security features, storage encryption, and automotive vehicle-system isolation, reflecting uses of Android beyond phones.
• A standalone application can generally be treated as an independent package because its code is available together, apart from material it may download. A preinstalled application can instead assume the presence of particular hardware or cooperating system components.
• Method names and intent names are not reliable evidence of actual behavior during reverse engineering. Names can guide an investigation, but analysts must trace the code and data flow because assumptions based on labels can lead in the wrong direction.
• The Device Monitoring receiver accepted a load URL intent containing URL and package-name fields, inserted those values into a database, and sent the database to a remote server. That behavior alone did not establish maliciousness because the data context was unknown.

Questions & Answers

Q: Why is Android system-image analysis more complex than standalone app analysis?

Android system-image analysis must account for code supplied with hardware components, software integrated by device manufacturers, and features added by third parties. Unlike an independent app, a preinstalled component can assume that specific hardware, services, or other components exist on its target device. Its behavior may therefore remain unclear when researchers examine the package in isolation.

Q: What organizations contribute software to an Android device?

Software can enter an Android device through several parts of its supply chain. Hardware components such as Wi-Fi chips, systems on chips, and proprietary security chips arrive with supporting code. An original device manufacturer assembles these pieces, third-party companies may add software features, and the original equipment manufacturer integrates and markets the completed device.

Q: What tests are applied to an Android system image?

The described testing process includes a compatibility test suite for requirements associated with the Android Open Source Project, a Google Mobile Services test suite for devices licensing Google applications or services, vendor testing for hardware abstraction layer compatibility, security tests for correctly applied patches, and a build test suite that reviews the complete image for malware or harmful behavior.

Q: What does the Android Compatibility Definition Document cover?

The Android Compatibility Definition Document provides a broad list of platform requirements. The security model section described in the source includes permissions, premium SMS warnings, security features, storage encryption, and automotive vehicle-system isolation. These varied subjects show that compatibility requirements address multiple Android configurations and uses, rather than focusing exclusively on ordinary mobile phones.

Q: Why must Android reverse engineers avoid assumptions based on code names?

Method names, class names, and intent labels can suggest what code might do, but they are not proof of its actual behavior. A reverse engineer should follow control flow and data flow to determine what happens. In the case study, a method name accurately described database insertion, but such names can also misdirect an investigation.

Q: What did the Device Monitoring application do with load URL intents?

The Device Monitoring application contained a broadcast receiver that checked whether an incoming intent represented the load URL action. It then extracted two extra fields, a URL and a package name, and passed them to a method that inserted the values into a database. The application subsequently transmitted that database to a remote server.

Q: Why was the Device Monitoring behavior not automatically classified as malicious?

Receiving data, storing it in a database, and transmitting it remotely did not by itself reveal what the data represented or why it was collected. The examined application depended on another source to provide the URL and package name. Without understanding that surrounding component and the context of those values, the observed operations alone were insufficient to establish malicious intent.

Q: How do hardware components affect Android security analysis?

Each hardware component can introduce supporting software needed to operate the hardware and expose it to other parts of the device. Consequently, a reverse engineer has more to inspect than the core Android operating system. Wi-Fi chips, systems on chips, security chips, and other device-specific features may all contribute code to the final system image.

Summary & Key Takeaways

• An Android device combines numerous hardware components, and each component may bring supporting software into the final system image. An original device manufacturer assembles these elements, third parties may contribute software features, and the original equipment manufacturer prepares the marketed product, creating a supply chain with code from multiple organizations.

• Android system images undergo several forms of testing. Compatibility testing checks requirements associated with the Android Open Source Project, while other suites cover Google Mobile Services, the hardware abstraction layer, security patch application, and harmful behavior. The build test suite reviews the complete system image for malware and other potentially harmful activity.

• System-image analysis differs from standalone app analysis because preinstalled software can rely on device-specific hardware, services, and cooperating components. In the Device Monitoring case, a broadcast receiver accepted a URL and package name, saved them to a database, and transmitted that database remotely, yet its significance depended on missing contextual information.
