How to Calculate Angular Velocity Using Instantaneous Center of Rotation

TL;DR

To calculate angular velocity using the instantaneous center of rotation (ICR), first identify the ICR based on the geometry and direction of velocities in the mechanism. For the given problem, the angular velocity of rod BC is determined to be 1 radian per second, and the velocity at point C is 0.77 meters per second.

Transcript

hello students in this video we will see the next example where we are going to use the concept of icr and find out the velocities of the links that are given to us this is the next example that we have in this we can see that it states rod a b is having an angular velocity of two radians per second and it is going counter clockwise so it is in thi... Read More

Key Insights

• ❓ The concept of the instantaneous center of rotation (ICR) is crucial for analyzing the velocities of mechanism components.
• 🍻 The angular velocity of linked rods remains the same throughout the mechanism.
• 😥 The velocity of a point can be calculated by multiplying the angular velocity by the distance from the ICR to that point.

Questions & Answers

Q: How is the velocity of point B calculated?

The velocity of point B is calculated by multiplying the angular velocity of rod AB (2 radians per second) by the distance between point B and the center of rotation A (0.3 meters). This gives a velocity of 0.6 meters per second.

Q: How is the length IB (distance from the ICR to point B) determined?

The length IB is determined using the sine rule. With the given angle of 40 degrees in triangle IBC and the known length BC (0.5 meters), the length IB is calculated to be 0.595 meters.

Q: How is the angular velocity of rod BC found?

The angular velocity of rod BC is equal to the angular velocity of rod AB, as both rods are connected. Therefore, the angular velocity of rod BC is 2 radians per second.

Q: How is the velocity at point C calculated?

The velocity at point C is found by multiplying the angular velocity of rod BC (1 radian per second) by the distance from the ICR to point C (0.77 meters). This gives a velocity of 0.77 meters per second.

Summary & Key Takeaways

• The example involves a mechanism with a rotating rod AB and a free-moving rod BC.

• The angular velocity of rod AB is given as 2 radians per second in a counterclockwise direction.

• By finding the instantaneous center of rotation (ICR) and using velocity calculations, the angular velocity of rod BC is determined to be 1 radian per second and the velocity at point C is calculated as 0.77 meters per second.
