Measurement of Angular Velocity

TL;DR

Different methods such as electrical tachometers, digital methods, and stroboscopic methods are used to measure angular velocity.

Transcript

do subscribe to ekeeda and press bell icon to get updates about latest engineering hsc and iit-jee mains and advanced videos hello friends in this video we are going to study about the measurement of angular velocity we will see the various transducer used for the measurement of angular velocity their construction working advantages disadvantages a... Read More

Key Insights

• 📐 Electrical tachometers, including DC and AC tachometer generators, are commonly used for measuring angular velocity.
• 🉐 Digital methods, such as photoelectric and inductive tachometers, provide advantages such as no physical contact, easy transmission of data, and a digital output.
• 🔦 Stroboscopic methods utilize a strobotron to flash light on a rotating object, enabling the measurement of rotational speed.

Questions & Answers

Q: What is angular velocity?

Angular velocity refers to the rate of change of the angular position of a rotating body. It is related to objects that are in rotation.

Q: What are the components of a DC tachometer?

The main components of a DC tachometer are an armature, permanent magnet, moving coil voltmeter, commutator, and brushes.

Q: How is the direction of rotation indicated by a DC tachometer?

The direction of rotation is indicated by the polarity of the output voltage. Clockwise rotation produces a different polarity than counterclockwise rotation.

Q: What are the advantages of digital methods for measuring angular velocity?

Digital methods have no direct physical contact with the object being measured, resulting in no load on the shaft. They also provide a digital output, allowing for easy transmission of information.

Q: What are the limitations of using a photoelectric tachometer?

The light source in a photoelectric tachometer needs to be replaced after a certain number of hours of use. Additionally, accuracy is dependent on factors such as gating period and the number of pulses generated per revolution.

Q: How does the toothed rotor variable reluctance tachometer work?

This tachometer has a rotor with multiple teeth and a magnetic pickup with a coil. As the teeth pass by the pickup, the inductance changes, producing an induced EMF. The frequency of these pulses is proportional to the speed of rotation.

Q: What advantage do stroboscopic methods have over other measurement methods?

Stroboscopic methods impose no load on the shaft and are convenient for spot checks. However, they cannot be used in environments with multiple light sources and may be less accurate than digital methods.

Summary & Key Takeaways

• Electrical tachometers, including DC and AC tachometer generators, are used to measure angular velocity by generating an output voltage proportional to the speed of rotation.

• Digital methods such as photoelectric tachometers and inductive tachometers use pulses or frequency measurements to determine angular velocity.

• Stroboscopic methods involve using a strobotron to flash light on a rotating object, with the frequency of the flashes corresponding to the object's rotational speed.
