What is RS232 and What is it Used for?

TL;DR

RS-232 is a legacy serial communication standard still used for connecting PLCs and various devices, though USB and Ethernet have become more prevalent.

Transcript

today you'll learn about rs-232 it's a phrase you may hear fairly regularly in industry especially by the older guys hopefully this video will clear some things up for you before we get into today's video if you love our videos be sure to click the like button below and make sure to click Subscribe and the bell to receive notifications of new real ... Read More

Key Insights

• 🍝 RS-232 is a legacy serial communication standard that was widely used in the past but has been phased out by USB and Ethernet.
• 🖱️ PLCs use RS-232 to communicate with various devices, including operator interfaces, computers, motor controllers, and vision systems.
• 🚠 To connect DTE and DCE devices in RS-232 communication, a reverse null modem cable is required.
• 🐎 Although RS-232 has limitations in terms of speed and cable length, it is still used by many manufacturers due to its cost-effectiveness and compatibility with existing systems.

Questions & Answers

Q: What is RS-232 and how does it work?

RS-232, a serial communication standard, uses positive and negative voltages to transmit binary signals. It allows devices, like PLCs and computers, to communicate by sending and receiving commands via voltage signals.

Q: What are the two types of devices in RS-232 communication?

The two types are Data Terminal Equipment (DTE), such as a computer, and Data Communications Equipment (DCE), like a modem. DTE and DCE devices require a reverse null modem cable to communicate with each other effectively.

Q: Is RS-232 still widely used, despite the advent of USB and Ethernet?

Yes, RS-232 is still utilized by many manufacturers due to its widespread adoption and affordability. It is commonly used for connecting PLCs to devices like HMIs, input/output modules, and motor drives.

Q: What are the limitations of RS-232?

RS-232 has a slower data transfer rate of around 20 kilobytes per second and a maximum cable length of about 50 feet. Resistance and voltage loops can cause issues with longer cables, which is why newer technology is preferred for remote installations.

Key Insights:

• RS-232 is a legacy serial communication standard that was widely used in the past but has been phased out by USB and Ethernet.
• PLCs use RS-232 to communicate with various devices, including operator interfaces, computers, motor controllers, and vision systems.
• To connect DTE and DCE devices in RS-232 communication, a reverse null modem cable is required.
• Although RS-232 has limitations in terms of speed and cable length, it is still used by many manufacturers due to its cost-effectiveness and compatibility with existing systems.
• The standard DB9 cable is commonly used for RS-232 communication.

Summary & Key Takeaways

• RS-232 is a form of serial data transmission most commonly known as a serial connection.

• PLCs use RS-232 for communication with modules, such as operator interfaces, computers, motor controllers, or vision systems.

• RS-232 has limitations in terms of data transfer speed and maximum cable length, making it less suitable for remote installations.
