Introduction to Centroid & Centre of Gravity - Centroid & Centre of Gravity - Engineering Mechanics

TL;DR

Centroid is a single point about which the entire area of a plane figure acts, applicable only to 2D figures with no volume.

Transcript

let us take the new chapter in mechanics the name of the chapter is centroid and center of gravity here we have the first part as centroid and the second part of the chapter is center of gravity first let us understand what is centroid here i will be writing the definition of centroid centroid it is a single point about which entire area is acting ... Read More

Key Insights

• 😥 Centroid is a single point indicating the center of mass or balance of a plane figure.
• 🔇 It is applicable only to 2D figures without volume, such as rectangles, squares, circles, triangles, and composite figures.
• 🇧🇱 The position of the centroid can be determined by locating its coordinates, x bar and y bar.
• 🧘 The centroid remains constant regardless of the orientation or position of the plane figure.
• 💁 Multiple plane figures can be combined to form a composite figure with its own centroid.
• ⚖️ The concept of centroid helps in calculating the balance and stability of objects or structures.
• 😥 The total area of a plane figure can be represented by a single point, the centroid.

Questions & Answers

Q: What is the definition of centroid?

The centroid is a single point about which the entire area of a plane figure acts, irrespective of its position or orientation. It is applicable only to 2D figures without volume.

Q: Can the centroid change when the orientation of a figure is altered?

No, the centroid remains constant even if the position or orientation of the figure is changed. It is a fixed point that indicates the distribution of the figure's area.

Q: Are all 2D figures applicable to the concept of centroid?

Yes, all plane figures without volume can have a centroid. Examples include rectangles, squares, circles, triangles, semicircles, and composite figures made up of multiple plane figures.

Q: How is the centroid denoted and located?

The centroid is denoted by the letter "g." Its location is determined by the coordinates x bar (with respect to the y-axis) and y bar (with respect to the x-axis). These values indicate the position of the centroid within the plane figure.

Summary & Key Takeaways

• Centroid is the single point about which the entire area of a plane figure acts, regardless of its orientation.

• It is applicable to 2D figures without volume, such as rectangles, circles, triangles, and composite figures.

• The centroid is denoted by the letter "g" and its location is determined by the coordinates x bar and y bar.
