Commutation Failure - Faults and Protection - High Voltage Direct Current Transmission

TL;DR

This video discusses the concept of commutation failure in electrical systems, its causes, effects, and potential solutions.

Transcript

hello everyone welcome to ekeeda platform and this is raven jacket here your electrical faculty and in this video i'm going to talk about the commutation failure which is related to with the falls and your protection system so we will discuss one by one and what is the commutation failure what will be the cause of this and what are the effects of t... Read More

Key Insights

• ⚡ Commutation failure occurs when the transfer of current between thyristors in a circuit is not successful, causing voltage decrease.
• 😘 Large DC current and low AC side voltage are common causes of commutation failure.
• ⏫ There are two types of commutation failure: single and double, with the double failure being more severe.
• 🌉 Effects of commutation failure include zero bridge voltage and increased DC current.
• 🧑‍🏭 Recovery from commutation failure relies on factors such as the response of the gamma controller and the magnitude of the AC voltage.
• 🥺 Commutation failure can lead to consequential failures in series-connected bridges if not properly addressed.
• 😒 The use of smoothing reactors can help limit the rate of rise of current and prevent subsequent commutation failures.

Questions & Answers

Q: What is commutation failure in electrical systems?

Commutation failure refers to the unsuccessful transfer of current between thyristors in a circuit, resulting in voltage decrease and potential system issues.

Q: What are the causes of commutation failure?

The two main causes discussed in the video are large DC current, which increases the overlapping angle, and low AC side voltage due to faults or short circuits.

Q: How does commutation failure affect the system?

Commutation failure can lead to effects such as zero bridge voltage, increased DC current, and consequential failures in series-connected bridges.

Q: How can recovery from commutation failure be achieved?

Recovery depends on factors such as the response of the gamma controller, current control in the link, and the magnitude of the AC voltage.

Summary & Key Takeaways

• Commutation failure occurs when the transfer of current between thyristors in a circuit is not successful, leading to voltage decrease and various phenomena.

• The failure can be caused by factors such as large DC current and low AC side voltage due to faults or short circuits.

• There are two types of commutation failure: single and double, with the double failure being more severe.

• Effects of commutation failure include zero bridge voltage, increased DC current, and consequential failures in series-connected bridges.

• Recovery from commutation failure depends on factors such as the response of the gamma controller and the magnitude of the AC voltage.
