Line integral example 2 (part 2) | Multivariable Calculus | Khan Academy

TL;DR

Calculate the surface area of a building with a complex shape and multiple contours using line integrals.

Transcript

In the last video, we set out to figure out the surface area of the walls of this weird-looking building, where the ceiling of the walls was defined by the function f of xy is equal to x plus y squared, and then the base of this building, or the contour of its walls, was defined by the path where we have a circle of radius 2 along here, then we go ... Read More

Key Insights

• 🫥 Calculating surface area using line integrals can be done by breaking the contour into smaller parts.
• ❓ Each part of the contour requires a different parameterization and calculation.
• 🤗 Derivatives are used to derive the ds formula for line integrals.
• ❓ The antiderivative of the function is integrated and evaluated to find the surface area.

Questions & Answers

Q: How is the surface area of the building calculated?

The surface area is determined by calculating the line integrals along each part of the building's contour, breaking it into three non-closed line integrals.

Q: How is the parameterization for each part of the contour defined?

The parameterization for each part differs based on the shape and direction. For example, for the second wall along the y-axis, x is always 0 and y is 2 minus t, where t ranges from 0 to 2.

Q: What is the formula used to calculate the line integral?

The line integral is calculated by multiplying the function f of xy with a small distance ds along the path. The ds can be expressed as the square root of the derivatives of x and y squared.

Q: How are the surface areas of each wall calculated individually?

Each line integral is evaluated separately by substituting the function, parameterization, and ds formula. The antiderivative is then taken and evaluated within the given range to find the surface area.

Summary & Key Takeaways

• The content explains how to calculate the surface area of a peculiar building with walls defined by a mathematical function and contours.

• The surface area calculation is broken down into three separate line integrals, corresponding to each part of the building's contour.

• The first wall's surface area is found to be 4 plus 2 pi, and the second wall's surface area is 8/3. The third wall's surface area is 2.
