Poles and Zeros of Network Functions (Problems) - Network Functions - Circuit Theory and Networks

TL;DR

Learn how to find poles and zeros of the impedance of a network by analyzing a given circuit in the s-domain.

Transcript

click the bell icon to get latest videos from equator hello friends welcome to Iran today we will see some simple numericals on poles and zeros of a network let us see what it is so here you can see there is problem number 1 which is asking us to find poles and zeros of the impedance of following network so impedance is their office and it's alread... Read More

Key Insights

• ❓ The impedance of a network can be found by replacing inductors and capacitors with their respective impedances.
• 💈 Zeros and poles of a network's impedance are vital for determining its frequency response.
• 0️⃣ Zeros indicate frequencies at which the impedance is zero, while poles represent frequencies at which the impedance is infinite.
• 💈 Poles and zeros provide insights into the behavior and stability of the network.
• 💈 Poles can determine the resonant frequencies of the network.
• ❓ The impedance function is obtained by finding the parallel combination of resistances and impedances.
• 0️⃣ Zeros and poles can be found by solving the numerator and denominator of the impedance function for values of 's' that make them equal to zero.

Questions & Answers

Q: How do you find the impedance of a network?

The impedance of a network is found by replacing the inductor and capacitor with their respective impedances and then calculating the parallel combination of resistances and impedances.

Q: What is the purpose of finding the poles and zeros of a network's impedance?

Finding the poles and zeros helps in understanding the frequency response and stability of the network. Zeros represent frequencies at which the impedance is zero, while poles represent frequencies at which the impedance is infinite.

Q: What do the zeros and poles of a network tell us about the circuit?

Zeros and poles provide insights into the behavior and characteristics of the network. Zeros indicate the frequencies at which the network might cancel or attenuate specific components, while poles indicate the frequencies where the network might amplify or resonate.

Q: How are zeros and poles related to the impedance function?

Zeros and poles are directly related to the factors of the impedance function. Zeros occur when the numerator of the impedance function equals zero, and poles occur when the denominator equals zero.

Summary & Key Takeaways

• The video demonstrates how to find the poles and zeros of the impedance in a network by replacing the inductor and capacitor with their respective impedances.

• The impedance function is determined by finding the parallel combination of resistances and adding the impedance of the inductor and capacitor.

• Zeros are found by identifying the values of 's' that make the numerator of the impedance function equal to zero, while poles are determined by finding the values of 's' that make the denominator zero.
