Combines SONET and WDM Network Design - Optical Networks

TL;DR

Sonic WDM network design is a cost-efficient solution for optical networking with potential commercial deployment, providing significant cost savings and efficient traffic grooming.

Transcript

hello students here we are going to learn about combined sonic wdm network design so uh wavelength uh division multiplexing he has enjoyed quick and very successful commercial acceptance due to his simplicity and low cost in comparison to alternative of tdm solutions so the optical networking based on the wavelength routing is a believed to take a ... Read More

Key Insights

• 💿 Sonic WDM offers a simple and cost-effective solution for optical networking.
• 🧭 Optical pass-through and traffic grooming can result in substantial cost savings.
• ✋ Consideration of higher layer needs, such as SONET, is crucial for network optimization.
• 🙂 SONET rings impose constraints on light path usage but offer flexibility for network integration.
• 🫥 The Sonic ADM network design includes various elements like ADM lines, interfaces, and cross-connects.
• 🍻 The physical topology of the network is interconnected via WDM links.
• 🫥 Goals include minimizing overall solution costs, involving optical nodes, amplifiers, switches, and line interfaces.

Questions & Answers

Q: Why is Sonic WDM considered a cost-effective solution?

Sonic WDM is cost-effective due to its simplicity and low cost compared to TDM solutions. Optical pass-through and grooming of traffic streams further reduce costs.

Q: How is traffic groomed in Sonic WDM networks?

Traffic can be grouped into light paths to avoid dropouts. The termination of traffic streams should be in a part of the network to optimize costs.

Q: What are the characteristics of SONET rings in network design?

SONET rings can be either uni-directional or bi-directional, imposing additional constraints on the use of light paths. SONET rings can also be interconnected and routed from one ring to another.

Q: What elements are involved in the Sonic ADM network design?

The ADM network design consists of high-speed ADM lines, lower-speed interfaces, interconnections, optical amplifiers, optical switches, and digital cross-connects.

Summary & Key Takeaways

• Sonic WDM, based on wavelength routing, is a cost-effective alternative to TDM solutions in optical networking.

• Optical pass-through in the network allows for large savings by reducing the number of TDM line terminals.

• Traffic grooming through light paths can optimize network cost and consider higher layer needs, such as SONET.
