How to Install Two Outlets in One Box

TL;DR

You can easily add two outlets in one box by disconnecting the existing outlet, installing a new box, and wiring each outlet independently. Ensure to turn off the circuit breaker, identify the stud's location, and use pigtails for proper connections. Always prioritize safety by checking local codes and consider hiring a professional if needed.

Transcript

what's up y'all so today i'm going to be showing you how i'm going to go about taking the single outlet that you see in here behind me and i'm actually going to be adding an outlet there so i'll have two outlets instead of just this single one just to have more outlets to plug things into here in the garage now i did in the past upload a video that... Read More

Key Insights

• 💦 It is essential to shut off the circuit breaker before working on electrical outlets.
• 🥶 Identifying the location of the stud is crucial for installing an old work box.
• 🛜 Pigtails can be used to wire outlets independently, ensuring that one faulty outlet does not affect others.
• 🛜 Ground wires, neutral wires, and hot wires should be connected to the corresponding terminals on the outlets.
• 🏆 It is important to test the wiring using an outlet tester before installing the faceplate.
• 👨‍💻 Following local codes and regulations is necessary for a safe and compliant installation.
• ❓ Hiring a professional is recommended if the DIY installation is not comfortable.

Questions & Answers

Q: How do I safely remove the old outlet?

To safely remove the old outlet, first shut off the circuit breaker supplying electricity to the outlet. Then, remove the front plate and disconnect all wiring from the terminals.

Q: How can I determine the location of the stud for the new box?

There are a few ways to determine the stud location. You can use a stud finder or look for nail pops in the drywall. In this video, the presenter uses a gap in the wall where the stud is visible.

Q: Can I use power tools to remove the old box?

While power tools like an oscillating saw or a sawzall can be used, caution is advised. There may be plumbing or other wiring behind the wall, so it's important to be careful when using power tools to remove the old box.

Q: How are the old work boxes secured in the wall?

Old work boxes are secured in the wall by turning screws on the box to flip up levers, which then go behind the drywall. As the screws are tightened, the levers sandwich the drywall to hold the box in place.

Key Insights:

• It is essential to shut off the circuit breaker before working on electrical outlets.
• Identifying the location of the stud is crucial for installing an old work box.
• Pigtails can be used to wire outlets independently, ensuring that one faulty outlet does not affect others.
• Ground wires, neutral wires, and hot wires should be connected to the corresponding terminals on the outlets.
• It is important to test the wiring using an outlet tester before installing the faceplate.
• Following local codes and regulations is necessary for a safe and compliant installation.
• Hiring a professional is recommended if the DIY installation is not comfortable.
• Proper use of wire nuts and electrical tape is essential to secure connections and prevent accidents.

Summary & Key Takeaways

• This video provides a comprehensive tutorial on adding an extra outlet in a garage by removing the old outlet, installing a new box, and wiring the new outlets.

• The presenter emphasizes the importance of checking local codes and hiring a professional if necessary.

• The process involves shutting off the circuit breaker, removing the old outlet, identifying the stud location, cutting a hole for the new box, installing the old work box, wiring the outlets independently using pigtails, and testing the wiring.
