This video discusses the causes and classifications of over voltages in converter stations, including disturbances on the AC and DC sides and internal faults.

Transcript

hello everyone welcome to igita platform and this is raven janket here your electrical faculty and in this video i am going to talk about the over voltages in the converter station we have already talked about the over current in the converter stations now we are actually talking about the over voltages and bro if we are talking about the over volt... Read More

Key Insights

• 🚉 Over voltages in converter stations can be caused by disturbances on both the AC and DC sides, as well as internal faults within the station.
• ⚡ The classifications of over voltages in the AC system include switching over voltages, temporary over voltages, and step front over voltages.
• ⚡ Switching over voltages have a wavefront duration of more than 100 milliseconds, and step front over voltages have a wavefront duration of 0.323 milliseconds.
• ⚡ Temporary over voltages are short-lasting over voltages that recover on their own within a few seconds.
• 🚉 Proper connection and protection systems are crucial in preventing over voltages in converter stations.
• ✊ Over voltages can pose risks to equipment and power system stability, so effective monitoring and mitigation strategies are necessary.
• 🚉 Careful design and maintenance of converter stations can help minimize the occurrence and impact of over voltages.

Questions & Answers

Q: What are the main causes of over voltages in converter stations?

Over voltages in converter stations can be caused by disturbances on the AC side, disturbances on the DC side, and internal faults within the converter station.

Q: How can disturbances on the AC side lead to over voltages?

If any disturbance or fault condition arises on the AC side, it can result in over voltages due to the mismatched conditions or faults in the AC system.

Q: How do disturbances on the DC side contribute to over voltages?

Disturbances occurring on the DC side of the converter station can lead to over voltages, possibly due to failures or faults in the DC system, which can cause voltage deviations.

Q: What is meant by temporary over voltages?

Temporary over voltages are over voltages that occur for a short duration and then recover on their own. These over voltages usually last for a few seconds.

Summary & Key Takeaways

• Over voltages in converter stations can occur due to disturbances on the AC and DC sides, as well as internal faults.

• The classifications of over voltages in the AC system include switching over voltages, temporary over voltages, and step front over voltages.

• Switching over voltages have a wavefront duration of more than 100 milliseconds, temporary over voltages last for a few seconds, and step front over voltages have a wavefront duration of 0.323 milliseconds.
