Slope and Deflection Double Integration Method Problem 2

TL;DR

Using the double integration method, this video explains how to calculate deflection at various points in a circular beam.

Transcript

hello friends here in this video we will see a problem on double integration method here is the question determine the deflection at points b c and d in the beam as shown in below here the figure is given the beam is circular in cross section having diameter of 200 mm take capital e young's modulus 200 gpa now this is the question we have i'll writ... Read More

Key Insights

• 😁 The double integration method is a widely used technique in structural engineering to calculate beam deflection.
• 😁 Support reactions are essential in analyzing beam deflection problems.
• ⚖️ Extending the UDL beyond its original limits helps balance the equations when applying the double integration method.
• 🖐️ Boundary conditions play a crucial role in determining the constants of integration in the deflection equation.
• 😁 Deflection calculation is essential for verifying the structural performance and stability of beams.
• 😁 Moment of inertia is required to determine the flexural rigidity of a beam.
• 😁 The deflection equation allows engineers to find the deflection at any point along the beam.

Questions & Answers

Q: What is the purpose of determining the deflection in a beam?

Deflection measurement is crucial in structural engineering as it helps ensure the beam's stability and structural integrity. It allows engineers to assess whether the beam can withstand the applied loads without excessive deformation.

Q: How are the support reactions calculated in the problem?

The support reactions are determined by applying the equations of equilibrium, considering the sum of vertical forces and the sum of moments around a point. By solving these equilibrium equations, the support reactions can be found.

Q: What is the significance of extending the UDL in the double integration method?

Extending the uniformly distributed load (UDL) beyond its original limits allows for balance in the equations when using the double integration method. Adding an equal and opposite UDL underneath the beam ensures that the extra UDL used to extend the original UDL is balanced.

Q: How do boundary conditions affect the calculation of constants in the deflection equation?

Boundary conditions, such as deflection at specific points, are used to calculate the constants of integration in the deflection equation. By substituting the given deflection values into the equation and solving for the constants, the complete deflection equation can be derived.

Summary & Key Takeaways

• The video introduces a problem on determining deflection at points B, C, and D in a circular beam.

• The beam has a diameter of 200 mm and a Young's modulus of 200 GPa.

• The video demonstrates the step-by-step solution using the double integration method, including finding support reactions, calculating moment of inertia, and solving for deflection equations.
