The Bizarre Paths of Groundwater Around Structures

TL;DR

Groundwater can pose significant challenges for structures such as dams and caissons, leading to erosion, uplift pressure, and potential failures.

Transcript

In 2015, an unusual incident happened on the  construction site for a sewage lift station   in British Columbia, Canada. WorksafeBC, the  provincial health and safety agency, posted a   summary of the event on YouTube. A steel caisson  had been installed to hold back soil while the   lift station could be constructed. One worker on  the site was su... Read More

Key Insights

• 👷 Groundwater can have a significant impact on subsurface structures, requiring engineers to consider its effects during design and construction.
• 🥺 Piping, erosion caused by groundwater, can compromise the foundation of structures and lead to rapid failure.
• 😲 Uplift pressure from groundwater can destabilize structures, such as dams, and must be properly accounted for in design.
• 🇼🇫 Cutoff walls, drains, and dewatering techniques are common methods used by engineers to mitigate the impact of groundwater on structures.
• 💐 The flow net is a graphical tool used by engineers to estimate the volume and pressure of seepage in the subsurface.
• 😲 Excavating a wide area of a dam's foundation or injecting high-pressure grout can create cutoff walls to prevent groundwater seepage.
• 😌 Drains installed below a dam can filter seepage and relieve uplift pressure, enhancing a structure's stability.

Questions & Answers

Q: How did the incident in British Columbia illustrate the impact of groundwater on subsurface structures?

The incident involved a steel caisson blowing out when a worker was pulled into a sinkhole. This incident was caused by the presence of groundwater within the soils, highlighting the importance of understanding and managing groundwater in construction.

Q: What is piping, and why is it a concern for structures?

Piping refers to the erosion of soil particles caused by water seeping below a structure. This can lead to the theft of soil from underneath a structure's foundation, creating a positive feedback loop of failure.

Q: How does uplift pressure from groundwater affect dams?

Uplift pressure counteracts the weight of a dam, potentially destabilizing it. Many concrete gravity dams have failed due to neglecting the uplift force, leading to catastrophic failures such as the St. Francis Dam disaster.

Q: What are some methods engineers use to mitigate the impact of groundwater on structures?

Engineers utilize cutoff walls, which can be excavated or created with grout, to cut off the flow of groundwater. Drains are also installed to filter seepage and relieve uplift pressure.

Key Insights:

• Groundwater can have a significant impact on subsurface structures, requiring engineers to consider its effects during design and construction.
• Piping, erosion caused by groundwater, can compromise the foundation of structures and lead to rapid failure.
• Uplift pressure from groundwater can destabilize structures, such as dams, and must be properly accounted for in design.
• Cutoff walls, drains, and dewatering techniques are common methods used by engineers to mitigate the impact of groundwater on structures.
• The flow net is a graphical tool used by engineers to estimate the volume and pressure of seepage in the subsurface.
• Excavating a wide area of a dam's foundation or injecting high-pressure grout can create cutoff walls to prevent groundwater seepage.
• Drains installed below a dam can filter seepage and relieve uplift pressure, enhancing a structure's stability.
• Other structures, such as retaining walls and caissons, also require considerations for groundwater impact and may utilize similar mitigation techniques.

Summary & Key Takeaways

• A construction incident in British Columbia, Canada highlighted the importance of considering the impact of groundwater on subsurface structures.

• Groundwater can cause erosion, known as piping, which can compromise the foundation of a structure.

• Uplift pressure from groundwater can also destabilize structures, as demonstrated by the failure of the St. Francis Dam in California in 1928.
